Description
8 ft. x 65.6 ft. Double Tab System Platon Foundation Wrap Membrane (525 sq. ft. per Roll) is a moisture barrier for both foundations and subfloors. It is a unique underlay solution that protects laminates, hardwood floors, and carpets from moisture, and can transform a cold, damp room into a dry, warm, and comfortable space. The Platon is a rugged, dimpled high-density polyethylene (HDPE) membrane that keeps foundations dry. Platon creates an impermeable vapour barrier and air gap, allowing concrete to breathe while controlling moisture.
Features
- Made from tough, durable High Density Polyethylene (HDPE)
- Creates an impermeable vapour barrier and air gap
- Solves problems associated with basement leakage and interior moisture control
- Lifelong protection against dampness rising through concrete floor
- Economical
- Can be installed in all weather conditions
- Double Tab membrane has blank space in the middle, so it can be divided into 2 separate 4 ft. piece
Specifications
| Length | 65.6′ (20m) |
| Height | 8′ (2.44m) |
| Minimum Sheet Thickness | 24mil in the flat sections21mil in the dimples |
| Dimple Height | 1/4″ (6mm) |
| Working Temperature | -50°C to 80°C (-58°F to 176ºF) |
| Softening Temperature | 125°C (257°F) |
| Thermal Resistance | R.68 |
| Water Vapor Permeability | 0.05 Perms |
| Air Volume/Dimple Side | 4.0 l/m² (1 gal/yd²) |
| UV Stabilization | Minimum 2% carbon black content |
| Recycled Plastic Content | +85% |
| Approvals | Canada – CCMC 12266R, CCMC 12878R, BMEC 91-6-154USA – ICC-ES Report ESR-2767 |
